DS1135LU-30
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable TIN LEAD delay line IC -40C~85C 2.7V 30ns 1.1mm
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 6999
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish TIN LEAD
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 20
JESD-30 Code S-PDSO-G8
Function Multiple, NonProgrammable
Qualification Status COMMERCIAL
Supply Voltage-Min (Vsup) 2.7V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Output Impedance 50Ohm
Number of Taps/Steps 1
Number of Independent Delays 3
Delay to 1st Tap 30ns
Programmable Delay Line NO
Total Delay-Nom (td) 30 ns
Dimensions
Height Seated (Max) 1.1mm
Compliance
RoHS Status Non-RoHS Compliant
