DS1110S-100
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Nonprogrammable TIN LEAD delay line IC -40C~85C 4.75V 10ns 2.65mm
PDF
/
Buying Options
Total Price: USD $70.97
Unit Price: USD $70.965
≥1 USD $70.965
≥10 USD $58.2274
≥100 USD $56.40815
≥500 USD $54.5889
≥1000 USD $52.7687
Inventory: 1152
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish TIN LEAD
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Supply Voltage 5V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Function Nonprogrammable
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 4.75V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 10
Number of Independent Delays 1
Delay to 1st Tap 10ns
Programmable Delay Line NO
Available Total Delays 100ns
Total Delay-Nom (td) 100 ns
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
