DS1100M-75+ image
Favorite
DS1100M-75+ image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description SILICON DELAY LINE Nonprogrammable MATTE TIN CMOS delay line IC -40C~85C 5V 15ns 7.62mm
PDF
/
Inventory: 9833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 7.62mm

Technical

Total Delay-Nom (td) 75 ns
Available Total Delays 75ns
Programmable Delay Line NO
Delay to 1st Tap 15ns
Number of Independent Delays 1
Number of Taps/Steps 5
Output Impedance 50Ohm
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Qualification Status COMMERCIAL
Function Nonprogrammable
JESD-30 Code R-PDIP-T8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish MATTE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
