DS1100M-500+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE Nonprogrammable MATTE TIN CMOS delay line IC -40C~85C 5V 100ns 7.62mm
PDF
/
Inventory: 6712
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish MATTE TIN
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDIP-T8
Function Nonprogrammable
Qualification Status COMMERCIAL
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 100ns
Programmable Delay Line NO
Available Total Delays 500ns
Total Delay-Nom (td) 500 ns
Dimensions
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
