DS1013S-50+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable MATTE TIN delay line IC 0C~70C 4.75V 50ns 10.285mm
PDF
/
Buying Options
Total Price: USD $28.71
Unit Price: USD $28.7052
≥1 USD $28.7052
≥10 USD $23.55335
≥100 USD $22.8171
≥500 USD $22.0818
≥1000 USD $21.34555
Inventory: 1406
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish MATTE TIN
Additional Feature BOTH LEADING & TRAILING EDGE ACCURACY; MAX FAN OUT OF 10 74LS LOAD PER OUTPUT
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PDSO-G16
Function Multiple, NonProgrammable
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 4.75V
Family CMOS
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 1
Number of Independent Delays 3
Delay to 1st Tap 50ns
Programmable Delay Line NO
Total Delay-Nom (td) 50 ns
Dimensions
Height Seated (Max) 2.67mm
Length 10.285mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
