DS1013S-20
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable TIN LEAD delay line IC 0C~70C 4.75V 20ns 10.285mm
PDF
/
Buying Options
Total Price: USD $6.55
Unit Price: USD $6.55215
≥1 USD $6.55215
≥10 USD $5.37605
≥100 USD $5.20885
≥500 USD $5.0407
≥1000 USD $4.87255
Inventory: 1594
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Length 10.285mm
Height Seated (Max) 2.67mm
Technical
Total Delay-Nom (td) 20 ns
Programmable Delay Line NO
Delay to 1st Tap 20ns
Number of Independent Delays 3
Number of Taps/Steps 1
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Family CMOS
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status COMMERCIAL
Function Multiple, NonProgrammable
JESD-30 Code R-PDSO-G16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Additional Feature BOTH LEADING & TRAILING EDGE ACCURACY; MAX FAN OUT OF 10 74LS LOAD PER OUTPUT
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
