DS1013M-150
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE Multiple NonProgrammable TIN LEAD CMOS delay line IC 0C~70C 2.22222MHz 4.75V 150ns
PDF
/
Buying Options
Total Price: USD $4.34
Unit Price: USD $4.33675
≥1 USD $4.33675
≥10 USD $3.5587
≥100 USD $3.44755
≥500 USD $3.3364
≥1000 USD $3.22525
Inventory: 1446
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 4.572mm
Technical
Input Frequency-Max (fmax) 2.22222MHz
Total Delay-Nom (td) 150 ns
Programmable Delay Line NO
Delay to 1st Tap 150ns
Number of Independent Delays 3
Number of Taps/Steps 1
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Family CMOS
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status COMMERCIAL
Function Multiple, NonProgrammable
JESD-30 Code R-PDIP-T8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Additional Feature BOTH LEADING & TRAILING EDGE ACCURACY; MAX FAN OUT OF 10 74LS LOAD PER OUTPUT
Terminal Finish TIN LEAD
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
