DS1010S-400
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Nonprogrammable TIN LEAD delay line IC 0C~70C 4.75V 40ns 2.65mm
PDF
/
Buying Options
Total Price: USD $48.45
Unit Price: USD $48.45095
≥1 USD $48.45095
≥10 USD $39.75465
≥100 USD $38.51205
≥500 USD $37.2704
≥1000 USD $36.0278
Inventory: 1165
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Total Delay-Nom (td) 400 ns
Available Total Delays 400ns
Programmable Delay Line NO
Delay to 1st Tap 40ns
Number of Independent Delays 1
Number of Taps/Steps 10
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status COMMERCIAL
Function Nonprogrammable
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
