DS1010-300
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE Nonprogrammable TIN LEAD CMOS delay line IC 0C~70C 2.08333MHz 4.75V 30ns
PDF
/
Inventory: 2075
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 4.572mm
Technical
Input Frequency-Max (fmax) 2.08333MHz
Total Delay-Nom (td) 300 ns
Available Total Delays 300ns
Programmable Delay Line NO
Delay to 1st Tap 30ns
Number of Independent Delays 1
Number of Taps/Steps 10
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status COMMERCIAL
Function Nonprogrammable
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
