DS1007S-1
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable TIN LEAD delay line IC 0C~70C 5V 3ns 10.3mm
PDF
/
Inventory: 915
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Terminal Finish TIN LEAD
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G16
Function Multiple, NonProgrammable
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.25V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 1
Number of Independent Delays 7
Delay to 1st Tap 3ns
Programmable Delay Line NO
Available Total Delays 3ns ~ 10ns, 9ns ~ 40ns
Total Delay-Nom (td) 18 ns
Dimensions
Height Seated (Max) 2.65mm
Length 10.3mm
Compliance
RoHS Status Non-RoHS Compliant
