DS1005S-250+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Nonprogrammable MATTE TIN delay line IC 0C~70C 5V 50ns 9.9mm
PDF
/
Inventory: 1550
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish MATTE TIN
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 30
Function Nonprogrammable
Qualification Status COMMERCIAL
Family CMOS/TTL
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 50ns
Programmable Delay Line NO
Available Total Delays 250ns
Total Delay-Nom (td) 250 ns
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
