DS1135U-20+
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable Matte Tin (Sn) delay line IC -40C~85C 2012 4.75V 20ns
PDF
/
Inventory: 7049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.1mm
Technical
Total Delay-Nom (td) 20 ns
Programmable Delay Line NO
Delay to 1st Tap 20ns
Number of Independent Delays 3
Number of Taps/Steps 1
Output Impedance 50Ohm
Prop. Delay@Nom-Sup 20 ns
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Supply Voltage-Min (Vsup) 4.75V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status Not Qualified
Function Multiple, NonProgrammable
JESD-30 Code S-PDSO-G8
Base Part Number DS1135
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Subcategory Delay Lines
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
