DS1110S-200+
RoHS
RoHS compliant
RoHS compliantPackage /
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING TIN CMOS delay line IC 150mA 2003 4.75V 200ns
PDF
/
Buying Options
Total Price: USD $7.4
Unit Price: USD $7.395566
≥1 USD $7.395566
≥200 USD $2.862122
≥500 USD $2.761029
≥1000 USD $2.712451
Inventory: 1368
Minimum: 1
-
+
Technical Details
Dimensions
Length 10.3mm
Width 7.5mm
Height Seated (Max) 2.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Technical
Total Delay-Nom (td) 200 ns
Programmable Delay Line NO
Number of Taps/Steps 10
Power Supply Current-Max (ICC) 150mA
Prop. Delay@Nom-Sup 200 ns
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Supply Voltage-Min (Vsup) 4.75V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.25V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Delay Lines
HTS Code 8542.39.00.01
Terminal Finish TIN
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Physical
Surface Mount YES
