DS1110E-450+
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
14-TSSOP (0.173 4.40mm Width) e3 DS1110 Active delay line circuit 5mm 45ns 5V 6Weeks
PDF
/
Buying Options
Total Price: USD $7.63
Unit Price: USD $7.633972
≥1 USD $7.633972
≥10 USD $7.201859
≥100 USD $6.794205
≥500 USD $6.409633
≥1000 USD $6.046826
Inventory: 1162
Minimum: 1
-
+
Technical Details
Technical
Number of Independent Delays 1
Number of Taps/Steps 10
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Operating Supply Voltage 5V
Qualification Status Not Qualified
Function Nonprogrammable
Base Part Number DS1110
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Operating Temperature -40°C~85°C
Total Delay-Nom (td) 450 ns
Available Total Delays 450ns
Programmable Delay Line NO
Delay to 1st Tap 45ns
Physical
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 5mm
