DS1100Z-50+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
Surface Mount SILICON DELAY LINE GULL WING Nonprogrammable delay line IC -40C~85C -1mA 6Weeks 5V
PDF
/
Buying Options
Total Price: USD $4.76
Unit Price: USD $4.756637
≥1 USD $4.756637
≥200 USD $1.840686
≥500 USD $1.776354
≥1000 USD $1.744844
Inventory: 1600
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Base Part Number DS1100
Function Nonprogrammable
Operating Supply Voltage 5V
Power Supplies 5V
Propagation Delay 50 ns
Turn On Delay Time 50 ns
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
High Level Output Current -1mA
Low Level Output Current 12mA
Output Impedance 50Ohm
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 10ns
Programmable Delay Line NO
Total Delay-Nom (td) 50 ns
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
