DS1100Z-45
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
IC DELAY LINE 5TAP 45NS 8SOIC
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 4009
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2002
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Matte Tin (Sn)
Voltage - Supply 4.75V~5.25V
Base Part Number DS1100
Function Nonprogrammable
Operating Supply Voltage 5V
Nominal Supply Current 30mA
Propagation Delay 45 ns
Logic IC Type SILICON DELAY LINE
High Level Output Current -1mA
Low Level Output Current 12mA
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 9ns
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
