DS1100U-40+
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
Surface Mount SILICON DELAY LINE GULL WING Nonprogrammable delay line IC -40C~85C 6Weeks 5V 8ns
PDF
/
Buying Options
Total Price: USD $8.42
Unit Price: USD $8.4216
≥1 USD $8.4216
≥10 USD $7.60584
≥100 USD $7.251728
≥500 USD $6.296576
≥1000 USD $6.013638
≥3000 USD $5.482998
Inventory: 75
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
Total Delay-Nom (td) 40 ns
Available Total Delays 40ns
Programmable Delay Line NO
Delay to 1st Tap 8ns
Number of Independent Delays 1
Number of Taps/Steps 5
Output Impedance 50Ohm
Prop. Delay@Nom-Sup 40 ns
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Power Supplies 5V
Operating Supply Voltage 5V
Function Nonprogrammable
Base Part Number DS1100
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Delay Lines
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
