DS1100M-60
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
8-DIP (0.300 7.62mm) e0 DS1100 Obsolete delay line circuit 7.62mm 12ns 5V 2011
PDF
/
Buying Options
Total Price: USD $4.21
Unit Price: USD $4.212101
≥1 USD $4.212101
≥10 USD $3.97368
≥100 USD $3.748754
≥500 USD $3.53656
≥1000 USD $3.336377
Inventory: 1530
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2011
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number DS1100
JESD-30 Code R-PDIP-T8
Function Nonprogrammable
Qualification Status Not Qualified
Power Supplies 5V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Prop. Delay@Nom-Sup 60 ns
Output Impedance 50Ohm
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 12ns
Programmable Delay Line NO
Available Total Delays 60ns
Total Delay-Nom (td) 60 ns
Dimensions
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
