DS1100M-250+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE Nonprogrammable Matte Tin (Sn) CMOS delay line IC -40C~85C 2011 5V 50ns
PDF
/
Inventory: 3680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Technical
Total Delay-Nom (td) 250 ns
Available Total Delays 250ns
Programmable Delay Line NO
Delay to 1st Tap 50ns
Number of Independent Delays 1
Number of Taps/Steps 5
Output Impedance 50Ohm
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Power Supplies 5V
Qualification Status Not Qualified
Function Nonprogrammable
JESD-30 Code R-PDIP-T8
Base Part Number DS1100
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Delay Lines
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
