DS1100LZ-20+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
Surface Mount SILICON DELAY LINE GULL WING Nonprogrammable delay line IC -40C~85C -1mA 6Weeks 3V
PDF
/
Buying Options
Total Price: USD $8.76
Unit Price: USD $8.756
≥1 USD $8.756
≥10 USD $7.9112
≥100 USD $7.54336
≥500 USD $6.549752
≥1000 USD $6.255366
≥3000 USD $5.703421
Inventory: 1156
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2002
Logic IC Type SILICON DELAY LINE
High Level Output Current -1mA
Low Level Output Current 8mA
Output Impedance 50Ohm
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 4ns
Programmable Delay Line NO
Total Delay-Nom (td) 20 ns
Output Polarity TRUE
Turn On Delay Time 20 ns
Propagation Delay 20 ns
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Function Nonprogrammable
Base Part Number DS1100L
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Subcategory Delay Lines
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Dimensions
Height 1.5mm
Length 5mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
