DS1100LU-30+
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Nonprogrammable Matte Tin (Sn) delay line IC -40C~85C 6Weeks 3V 6ns
PDF
/
Buying Options
Total Price: USD $9.24
Unit Price: USD $9.24
≥1 USD $9.24
≥10 USD $8.35032
≥100 USD $7.96224
≥500 USD $6.913632
≥1000 USD $6.602886
≥3000 USD $6.020291
Inventory: 115
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number DS1100L
JESD-30 Code S-PDSO-G8
Function Nonprogrammable
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Prop. Delay@Nom-Sup 30 ns
Output Impedance 50Ohm
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 6ns
Programmable Delay Line NO
Available Total Delays 30ns
Total Delay-Nom (td) 30 ns
Dimensions
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
