DS1044R-10+
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
Surface Mount SILICON DELAY LINE GULL WING Multiple NonProgrammable delay line IC 0C~70C 1998 5V 10ns
PDF
/
Inventory: 5272
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 1998
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish MATTE TIN
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS1044
Function Multiple, NonProgrammable
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Family CMOS
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 1
Number of Independent Delays 4
Delay to 1st Tap 10ns
Programmable Delay Line NO
Total Delay-Nom (td) 10 ns
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.91mm
Compliance
RoHS Status ROHS3 Compliant
