DS1023S-200+

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description Surface Mount SILICON DELAY LINE GULL WING 1-Shot Programmable delay line IC 0C~70C 60mA 10Weeks 5V
PDF
/
Buying Options
Total Price: USD $12.76
Unit Price: USD $12.76
≥1 USD $12.76
≥10 USD $11.72952
≥100 USD $11.243338
≥500 USD $10.699779
Inventory: 1194
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 7.6mm
Length 10.5mm
Height 2.35mm

Technical

Input Frequency-Max (fmax) 25MHz
Tap Increment 2ns
Total Delay-Nom (td) 524 ns
Available Total Delays 510ns
Programmable Delay Line YES
Delay to 1st Tap 16.5ns
Number of Independent Delays 1
Number of Taps/Steps 256
Power Supply Current-Max (ICC) 60mA
Prop. Delay@Nom-Sup 527 ns
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Family CMOS/TTL
Power Supplies 5V
Operating Supply Voltage 5V
Function 1-Shot, Programmable
Base Part Number DS1023
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Delay Lines
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature 0°C~70°C

Physical

Weight 473.692182mg
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin

Supply Chain

Factory Lead Time 10 Weeks
