DS1020S-50+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
Surface Mount SILICON DELAY LINE GULL WING Programmable delay line IC 0C~70C 30mA 3.63636MHz 5V
PDF
/
Buying Options
Total Price: USD $7.74
Unit Price: USD $7.7425
≥1 USD $7.7425
≥10 USD $6.35265
≥100 USD $6.1541
≥500 USD $5.95555
≥1000 USD $5.757
Inventory: 7103
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 1999
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Base Part Number DS1020
Function Programmable
Operating Supply Voltage 5V
Power Supplies 5V
Family CMOS
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Power Supply Current-Max (ICC) 30mA
Number of Taps/Steps 256
Number of Independent Delays 1
Delay to 1st Tap 10ns
Programmable Delay Line YES
Available Total Delays 137.5ns
Total Delay-Nom (td) 137.5 ns
Tap Increment 500ps
Input Frequency-Max (fmax) 3.63636MHz
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
