DS1013S-75+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NonProgrammable TIN delay line IC 0C~70C 1999 4.75V 75ns
PDF
/
Inventory: 6921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 10.285mm
Height Seated (Max) 2.67mm
Technical
Total Delay-Nom (td) 75 ns
Programmable Delay Line NO
Delay to 1st Tap 75ns
Number of Independent Delays 3
Number of Taps/Steps 1
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Family CMOS
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status Not Qualified
Function Multiple, NonProgrammable
JESD-30 Code R-PDSO-G16
Base Part Number DS1013
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Additional Feature BOTH LEADING & TRAILING EDGE ACCURACY; MAX FAN OUT OF 10 74LS LOAD PER OUTPUT
Terminal Finish TIN
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 1999
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
