DS1013-20+
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE Multiple NonProgrammable MATTE TIN CMOS delay line IC 0C~70C 1999 4.75V 20ns
PDF
/
Inventory: 1478
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 19.05mm
Height Seated (Max) 4.572mm
Technical
Total Delay-Nom (td) 20 ns
Programmable Delay Line NO
Delay to 1st Tap 20ns
Number of Independent Delays 3
Number of Taps/Steps 1
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Family CMOS
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status Not Qualified
Function Multiple, NonProgrammable
JESD-30 Code R-PDIP-T14
Base Part Number DS1013
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 1999
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
