DS1005S-100
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
16-SOIC (0.295 7.50mm Width) e0 DS1005 Obsolete delay line circuit 20ns 5V 1999 0C~70C
PDF
/
Buying Options
Total Price: USD $4.68
Unit Price: USD $4.68065
≥1 USD $4.68065
≥10 USD $3.84085
≥100 USD $3.7202
≥500 USD $3.6005
≥1000 USD $3.4808
Inventory: 5008
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Total Delay-Nom (td) 100 ns
Available Total Delays 100ns
Programmable Delay Line NO
Delay to 1st Tap 20ns
Number of Independent Delays 1
Number of Taps/Steps 5
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Family CMOS/TTL
Power Supplies 5V
Qualification Status Not Qualified
Function Nonprogrammable
Base Part Number DS1005
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Subcategory Delay Lines
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 1999
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
