DS1005M-175+
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
8-DIP (0.300 7.62mm) e3 DS1005 Obsolete delay line IC 7.62mm 35ns 5V 1999
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.4936
≥1 USD $3.4936
Inventory: 1788
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 1999
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS1005
JESD-30 Code R-PDIP-T8
Function Nonprogrammable
Qualification Status Not Qualified
Power Supplies 5V
Family CMOS/TTL
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 35ns
Programmable Delay Line NO
Available Total Delays 175ns
Total Delay-Nom (td) 175 ns
Dimensions
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
