CDCVF857DGG

Texas Instruments
RoHS
RoHS RoHS compliant
Package 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description SSTL-2 PLL Clock Driver 48-TFSOP (0.240 6.10mm Width) CDCVF857 clock generator ic 2.7V 220MHz 10mA 12.5mm
PDF
/
Buying Options
Total Price: USD $3.24
Unit Price: USD $3.23665
≥1 USD $3.23665
≥10 USD $2.6562
≥100 USD $2.5726
≥500 USD $2.48995
≥1000 USD $2.4073
Inventory: 8686
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Number of Pins 48
Weight 223.195796mg

Technical

Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 48
ECCN Code EAR99
Type PLL Clock Driver
Subcategory Clock Drivers
Voltage - Supply 2.3V~2.7V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.5mm
Frequency 220MHz
Base Part Number CDCVF857
Pin Count 48
Number of Outputs 10
Operating Supply Voltage 2.5V
Supply Voltage-Max (Vsup) 2.7V
Supply Voltage-Min (Vsup) 2.3V
Number of Circuits 1
Nominal Supply Current 10mA
Family 857
Output Characteristics 3-STATE
Input SSTL-2
Ratio - Input:Output 2:11
PLL Yes with Bypass
Differential - Input:Output Yes/Yes
Propagation Delay (tpd) 3.5 ns
Divider/Multiplier No/No
Same Edge Skew-Max (tskwd) 0.04 ns

Dimensions

Height 1.2mm
Length 12.5mm
Width 6.1mm
Thickness 1.15mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
