CDCM61002RHBR
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
LVCMOS Crystal Clock Generator 32-VFQFN Exposed Pad CDCM61002 clock generator circuit 3.6V 683.28MHz 340mW 108mA
PDF
/
Buying Options
Total Price: USD $5.8
Unit Price: USD $5.7992
≥1 USD $5.7992
≥10 USD $5.21224
≥100 USD $4.927648
≥500 USD $4.270464
≥1000 USD $4.05152
≥3000 USD $3.635403
Inventory: 1386
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-VFQFN Exposed Pad
Number of Pins 32
Weight 72.206235mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 32
Type Clock Generator
Packing Method TR
Max Power Dissipation 340mW
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Frequency 683.28MHz
Base Part Number CDCM61002
Output LVCMOS, LVDS, LVPECL
Pin Count 32
Number of Outputs 2
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Operating Supply Current 108mA
Load Capacitance 5pF
Input LVCMOS, Crystal
Ratio - Input:Output 1:3
PLL Yes with Bypass
Differential - Input:Output No/No
Divider/Multiplier Yes/No
Same Edge Skew-Max (tskwd) 0.05 ns
Dimensions
Height 1mm
Length 5mm
Width 5mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
