CDCF5801ADBQRG4
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
HSTL LVPECL LVTTL PLL Multiplier/Divider 24-SSOP (0.154 3.90mm Width) CDCF5801 clock generator circuit 3.6V 280MHz 75mA 8.65mm
PDF
/
Inventory: 2031
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.5mm
Width 3.9mm
Length 8.65mm
Height 1.75mm
Technical
fmax-Min 280 MHz
Divider/Multiplier Yes/Yes
Differential - Input:Output No/Yes
PLL Yes
Max I(ol) 0.04 A
Ratio - Input:Output 1:1
Input HSTL, LVPECL, LVTTL
Frequency (Max) 280MHz
Nominal Supply Current 75mA
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Number of Outputs 1
Pin Count 24
Output HSTL, LVDS, LVPECL, LVTTL, SSTL
Base Part Number CDCF5801
Frequency 240MHz
Terminal Pitch 0.64mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Packing Method TR
Subcategory Clock Drivers
Additional Feature DIFFERENTIAL/SINGLE-ENDED OUTPUT AVAILABLE
Type PLL Multiplier/Divider
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 129.500622mg
Number of Pins 24
Package / Case 24-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 8 Weeks
