CDC857-3DGGG4
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
LVTTL SSTL-2 PLL Clock Driver 48-TFSOP (0.240 6.10mm Width) CDC857 clock generator ic 2.7V 167MHz 235mA 0.5mm
PDF
/
Inventory: 4526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Divider/Multiplier No/No
Propagation Delay (tpd) 6 ns
Differential - Input:Output Yes/Yes
PLL Yes with Bypass
Ratio - Input:Output 1:10
Input LVTTL, SSTL-2
Nominal Supply Current 235mA
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.3V
Supply Voltage-Max (Vsup) 2.7V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 48
Output SSTL-2
Base Part Number CDC857
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 167MHz
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Subcategory Clock Drivers
Additional Feature ALSO REQUIRES 3.3V PLL VOLTAGE
Type PLL Clock Driver
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Packaging Tube
Operating Temperature 0°C~85°C
Physical
Number of Pins 48
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
