CDC7005RGZTG4
RoHS
/
Package VQFN EP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
LVCMOS VQFN EP PLL BASED CLOCK DRIVER e4 clock generator ic 3.6V 800MHz 7mm 0.06ns
PDF
/
Buying Options
Total Price: USD $23.64
Unit Price: USD $23.6436
≥1 USD $23.6436
≥10 USD $19.39995
≥100 USD $18.7929
≥500 USD $18.1868
≥1000 USD $17.5807
Inventory: 1372
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
Same Edge Skew-Max (tskwd) 0.06 ns
Logic IC Type PLL BASED CLOCK DRIVER
Input LVCMOS
Output Characteristics 3-STATE
Number of Inputs 1
Frequency (Max) 800MHz
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3.3V
Number of Outputs 5
Pin Count 48
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 138.005479mg
Number of Pins 48
Package / Case VQFN EP
Mount Surface Mount
Contact Plating Gold
