NB2308AC1DG

ON Semiconductor
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description Clock Zero Delay Buffer 16-SOIC (0.154 3.90mm Width) NB2308A clock generator ic 3.6V 133.3MHz 34mA 9.9mm
PDF
/
Inventory: 2168
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 3.9mm
Length 9.9mm

Technical

Number of True Outputs 8
Same Edge Skew-Max (tskwd) 0.2 ns
Differential - Input:Output No/No
PLL Yes with Bypass
Max I(ol) 0.008 A
Ratio - Input:Output 1:8
Input Clock
Output Characteristics 3-STATE
Frequency (Max) 133.3MHz
Nominal Supply Current 34mA
Number of Circuits 1
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 16
Base Part Number NB2308A
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Terminal Finish Tin (Sn)
Type Zero Delay Buffer
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2003
Packaging Tube
Operating Temperature 0°C~70°C

Physical

Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
