MC100EP139DWR2

ON Semiconductor
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description PECL SOIC LOW SKEW CLOCK DRIVER NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V clock generator ic 5.5V 1GHz 2.65mm 0.9ns
PDF
/
Inventory: 1166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case SOIC

Technical

Packaging Cut Tape (CT)
Published 2007
JESD-609 Code e0
Number of Terminations 20
Terminal Finish Tin/Lead (Sn80Pb20)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Subcategory Clock Drivers
Technology ECL
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 20
JESD-30 Code R-PDSO-G20
Supply Voltage-Max (Vsup) 5.5V
Power Supplies -3.0/-5.5/3.3/5.0V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Frequency (Max) 1GHz
Output Characteristics OPEN-EMITTER
Input PECL
Logic IC Type LOW SKEW CLOCK DRIVER
PLL No
Propagation Delay (tpd) 0.9 ns
Number of True Outputs 4

Dimensions

Height Seated (Max) 2.65mm
Width 7.5mm

Compliance

RoHS Status RoHS Compliant
Lead Free Contains Lead
