PL123-09HSC
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
Clock 16-SOIC (0.154 3.90mm Width) PL123 Surface Mount clock generator circuit 3.6V 134MHz 9.9mm 8.5ns
PDF
/
Buying Options
Total Price: USD $18.6
Unit Price: USD $18.60195
≥1 USD $18.60195
≥10 USD $15.26365
≥100 USD $14.78675
≥500 USD $14.30985
≥1000 USD $13.83295
Inventory: 1188
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 3.3V
Base Part Number PL123
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Frequency (Max) 134MHz
Output Characteristics 3-STATE
Input Clock
Ratio - Input:Output 1:9
PLL Yes with Bypass
Differential - Input:Output No/No
Propagation Delay (tpd) 8.5 ns
Same Edge Skew-Max (tskwd) 0.25 ns
Number of True Outputs 9
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
