MK3771-17R
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
DUAL Discontinued GULL WING COMMERCIAL (Type) IC 1999 0C 9.9mm 108MHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 7244
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Technical
PLL Yes
Primary Clock/Crystal Frequency-Nom 13.5MHz
Input Crystal
Frequency (Max) 108MHz
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, VIDEO
Number of Circuits 1
Temperature Grade COMMERCIAL
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.45V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Clock Generators
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 28
Part Status Discontinued
Pbfree Code no
JESD-609 Code e0
Published 1999
Physical
Package / Case SSOP
Mount Surface Mount
