841602AGILFT
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
Tin DUAL Active GULL WING (Type) IC 7Weeks -40C 7.7mm 87mA
PDF
/
Inventory: 8021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case TSSOP
Number of Pins 28
Technical
Published 2005
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 28
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Clock Generators
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 28
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Temperature Grade INDUSTRIAL
Number of Circuits 1
Max Supply Voltage 3.465V
Min Supply Voltage 3.015V
uPs/uCs/Peripheral ICs Type CLOCK GENERATOR, OTHER
Supply Current-Max 87mA
Frequency (Max) 125MHz
Input Crystal
Primary Clock/Crystal Frequency-Nom 25MHz
Dimensions
Length 7.7mm
Width 6.1mm
Thickness 1mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
