CY22392FC
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
LVTTL Crystal Clock Generator Fanout Distribution 16-TSSOP (0.173 4.40mm Width) CY22392 clock generator circuit 3.3V 200MHz 5mm 0C~70C
PDF
/
Buying Options
Total Price: USD $47.03
Unit Price: USD $47.02785
≥1 USD $47.02785
≥10 USD $38.5871
≥100 USD $37.3806
≥500 USD $36.17505
≥1000 USD $34.9695
Inventory: 1186
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.4mm
Length 5mm
Technical
Divider/Multiplier Yes/No
Differential - Input:Output No/No
PLL Yes with Bypass
Primary Clock/Crystal Frequency-Nom 166MHz
Ratio - Input:Output 1:6
Input LVTTL, Crystal
Number of Circuits 1
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Number of Outputs 6
Pin Count 16
Output LVCMOS
Base Part Number CY22392
Time@Peak Reflow Temperature-Max (s) 20
Frequency 200MHz
Reach Compliance Code not_compliant
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.135V~3.465V
Subcategory Clock Generators
Terminal Finish TIN LEAD
Type Clock Generator, Fanout Distribution
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Published 2000
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
