SN54HC244J
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL ENABLE LOW MILITARY Through Hole clock driver 150pF 125C 34ns -7.8mA
PDF
/
Buying Options
Total Price: USD $8.85
Unit Price: USD $8.8483
≥1 USD $8.8483
≥10 USD $7.2599
≥100 USD $7.03285
≥500 USD $6.80675
≥1000 USD $6.5797
Inventory: 6007
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 4.57mm
Width 6.92mm
Length 24.2mm
Height 5.08mm
Technical
Count Direction UNIDIRECTIONAL
Control Type ENABLE LOW
Low Level Output Current 7.8mA
High Level Output Current -7.8mA
Prop. Delay@Nom-Sup 34 ns
Logic IC Type BUS DRIVER
Output Characteristics 3-STATE
Logic Function Buffer
Family HC/UH
Turn On Delay Time 300 ns
Quiescent Current 8μA
Propagation Delay 300 ns
Number of Bits 4
Number of Ports 2
Load Capacitance 150pF
Min Supply Voltage 2V
Max Supply Voltage 6V
Temperature Grade MILITARY
Polarity Non-Inverting
Number of Elements 2
Operating Supply Voltage 5V
Number of Outputs 8
Pin Count 20
Supply Voltage 5V
Number of Functions 2
Terminal Position DUAL
Technology CMOS
Packing Method TUBE
Subcategory Bus Driver/Transceivers
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 20
Physical
Number of Pins 20
Package / Case CDIP
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
