JM38510/32203BFA

Texas Instruments
RoHS
/
Package /
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description DUAL Not Qualified MILITARY Surface Mount clock driver 125C 40ns -1mA 6.73mm
PDF
/
Buying Options
Total Price: USD $11.82
Unit Price: USD $11.8184
≥1 USD $11.8184
Inventory: 117
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mount Surface Mount
Number of Pins 16

Technical

Number of Terminations 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature ONE FUNCTION WITH TWO BITS
Technology TTL
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 2
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Number of Outputs 6
Qualification Status Not Qualified
Output Type TTL
Operating Supply Voltage 5V
Number of Elements 2
Polarity Non-Inverting
Temperature Grade MILITARY
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of Ports 2
Number of Bits 4
Propagation Delay 40 ns
Turn On Delay Time 40 ns
Family LS
Logic Function Buffer
Output Characteristics 3-STATE
Logic IC Type BUS DRIVER
Screening Level MIL-M-38510 Class B
High Level Output Current -1mA
Low Level Output Current 12mA

Dimensions

Height 2.03mm
Length 10.3mm
Width 6.73mm
Thickness 1.65mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
