DS0026CMM
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
DUAL Surface Mount MOS Fanout Buffer (Distribution) clock driver 0C~70C 10MHz 10V 3mm
PDF
/
Inventory: 7943
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type Fanout Buffer (Distribution)
Technology MOS
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Terminal Pitch 0.65mm
Frequency 10MHz
Base Part Number DS0026
Output MOS
Pin Count 8
Supply Voltage-Min (Vsup) 10V
Number of Circuits 2
Input TTL
Ratio - Input:Output 2:2
Differential - Input:Output No/No
Dimensions
Height Seated (Max) 1.09mm
Length 3mm
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
