CDCM1804RTHR
RoHS
/
Package 24-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
CML HSTL LVDS LVPECL LVTTL SSTL-2VML CDCM1804 24-VFQFN Exposed Pad Obsolete clock buffer 4mm 3.3V 2.6ns 800MHz
PDF
/
Buying Options
Total Price: USD $9.84
Unit Price: USD $9.84295
≥1 USD $9.84295
≥10 USD $8.0769
≥100 USD $7.8242
≥500 USD $7.5715
≥1000 USD $7.31975
Inventory: 1251
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Number of Pins 24
Weight 40.39807mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 24
Type Fanout Buffer (Distribution), Divider, Multiplexer
Subcategory Clock Drivers
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CDCM1804
Output LVCMOS, LVPECL
Pin Count 24
Number of Outputs 3
Qualification Status Not Qualified
Supply Voltage-Min (Vsup) 3V
Number of Circuits 1
Frequency (Max) 800MHz
Input CML, HSTL, LVDS, LVPECL, LVTTL, SSTL-2, VML
Ratio - Input:Output 1:4
Differential - Input:Output Yes/Yes
Prop. Delay@Nom-Sup 2.6 ns
Propagation Delay (tpd) 2.6 ns
fmax-Min 800 MHz
Dimensions
Height Seated (Max) 0.9mm
Length 4mm
Width 4mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
