CDC391DR image
Favorite
CDC391DR image
Favorite
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description DUAL Gold TRUE Surface Mount Clock Fanout Buffer (Distribution) IC -40C~85C 100MHz 770mW 5ns
PDF
/
Buying Options
Total Price: USD $5.53
Unit Price: USD $5.52995
≥1 USD $5.52995
≥10 USD $4.53815
≥100 USD $4.39565
≥500 USD $4.2541
≥1000 USD $4.11255
Inventory: 1332
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3.9mm
Length 9.9mm

Technical

Prop. Delay@Nom-Sup 5 ns
Differential - Input:Output No/No
Max I(ol) 0.048 A
Ratio - Input:Output 1:6
Output Polarity TRUE
Input TTL
Output Characteristics 3-STATE
Turn On Delay Time 7 ns
Quiescent Current 40mA
Propagation Delay 7 ns
Number of Bits 1
Power Dissipation 770mW
Nominal Supply Current 40mA
Number of Ports 2
Number of Circuits 1
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 6
Pin Count 16
Base Part Number CDC391
Frequency 100MHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology BICMOS
Max Power Dissipation 770mW
Subcategory Clock Drivers
Type Fanout Buffer (Distribution)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Weight 155.100241mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
