CDC2351QDBG4
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
Automotive AEC-Q100 DUAL Gold Surface Mount Clock Fanout Buffer (Distribution) IC 50pF -40C~125C 100MHz 650mW
PDF
/
Buying Options
Total Price: USD $13.09
Unit Price: USD $13.08815
≥1 USD $13.08815
≥10 USD $10.73975
≥100 USD $10.40345
≥500 USD $10.0681
≥1000 USD $9.73275
Inventory: 1609
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SSOP (0.209, 5.30mm Width)
Number of Pins 24
Weight 172.39345mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series Automotive, AEC-Q100
JESD-609 Code e4
Pbfree Code yes
Same Edge Skew-Max (tskwd) 2.5 ns
Differential - Input:Output No/No
Ratio - Input:Output 1:10
Input LVTTL
Output Characteristics 3-STATE WITH SERIES RESISTOR
Frequency (Max) 100MHz
Turn On Delay Time 12 ns
Quiescent Current 15mA
Propagation Delay 12 ns
Power Dissipation 650mW
Nominal Supply Current 7.85mA
Load Capacitance 50pF
Number of Circuits 1
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Number of Outputs 10
Pin Count 24
Base Part Number CDC2351
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology BICMOS
Max Power Dissipation 650mW
Packing Method TR
Subcategory Clock Drivers
Type Fanout Buffer (Distribution)
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 8.2mm
Height 2mm
