CDC2351MDBREPG4
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
Clock Drivers & Distribution 1 to 10-Line 3.3V Clock Driver
PDF
/
Buying Options
Total Price: USD $27.5
Unit Price: USD $27.50155
≥1 USD $27.50155
≥10 USD $22.56535
≥100 USD $21.86045
≥500 USD $21.15555
≥1000 USD $20.4497
Inventory: 1516
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Length 8.2mm
Height Seated (Max) 2mm
Technical
Same Edge Skew-Max (tskwd) 2.5 ns
Logic IC Type LOW SKEW CLOCK DRIVER
Input LVTTL
Output Characteristics 3-STATE WITH SERIES RESISTOR
Frequency (Max) 100MHz
Turn On Delay Time 12 ns
Quiescent Current 15mA
Propagation Delay 12 ns
Power Dissipation 650mW
Power Dissipation-Max 650mW
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Number of Circuits 1
Temperature Grade MILITARY
Operating Supply Voltage 3.3V
Number of Outputs 10
Pin Count 24
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Clock Drivers
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 172.39345mg
Number of Pins 24
Package / Case SSOP
Mount Surface Mount
