MC10H645FN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
QUAD COMMERCIAL Surface Mount ECL Clock Fanout Buffer (Distribution), Multiplexer IC 0C~85C 0.65ns 5V 4.57mm
PDF
/
Buying Options
Total Price: USD $12.44
Unit Price: USD $12.44215
≥1 USD $12.44215
≥10 USD $10.20965
≥100 USD $9.89045
≥500 USD $9.57125
≥1000 USD $9.25205
Inventory: 16008
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature 0°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Type Fanout Buffer (Distribution), Multiplexer
Terminal Finish TIN LEAD
Technology ECL
Voltage - Supply 4.75V~5.25V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 28
JESD-30 Code S-PQCC-J28
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 4.75V
Number of Circuits 1
Family 10H
Input TTL
Ratio - Input:Output 2:9
Differential - Input:Output Yes/Yes
Propagation Delay (tpd) 5.8 ns
Same Edge Skew-Max (tskwd) 0.65 ns
Number of True Outputs 9
Dimensions
Height Seated (Max) 4.57mm
Compliance
RoHS Status Non-RoHS Compliant
