MC100E310FNG
RoHS
RoHS compliant
RoHS compliantPackage 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
100E QUAD COMMERCIAL Surface Mount Clock Fanout Buffer (Distribution), Multiplexer IC -40C~85C 900MHz 0.05ns 5V
PDF
/
Inventory: 8395
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 4.57mm
Technical
Same Edge Skew-Max (tskwd) 0.05 ns
fmax-Min 700 MHz
Propagation Delay (tpd) 0.8 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 2:8
Input ECL, PECL
Frequency (Max) 900MHz
Number of Circuits 1
Supply Voltage-Min (Vsup) 4.2V
Supply Voltage-Max (Vsup) 5.7V
Qualification Status COMMERCIAL
JESD-30 Code S-PQCC-J28
Pin Count 28
Output ECL, PECL
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form J BEND
Terminal Position QUAD
Voltage - Supply 4.2V~5.7V
Technology ECL
Additional Feature NECL MODE: 0V VCC WITH VEE = -4.2V TO -5.7V
Terminal Finish MATTE TIN
Type Fanout Buffer (Distribution), Multiplexer
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Series 100E
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
