NBSG14MN
RoHS
/
Package 16-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
QUAD Not Qualified Surface Mount ECL Clock Fanout Buffer (Distribution), Data IC -40C~85C 12GHz 160ps -2.5/-3.3/2.5/3.3V
PDF
/
Buying Options
Total Price: USD $55.5
Unit Price: USD $55.501098
≥1 USD $55.501098
≥10 USD $52.359527
≥100 USD $49.39578
≥500 USD $46.599792
≥1000 USD $43.962065
Inventory: 1160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:4
Input CML, LVCMOS, LVDS, LVTTL, NECL, PECL, RSECL
Family 14
Frequency (Max) 12GHz
Propagation Delay 160 ps
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Power Supplies -2.5/-3.3/2.5/3.3V
Supply Voltage-Max (Vsup) 3.465V
Qualification Status Not Qualified
Number of Outputs 8
Pin Count 16
Output RSECL, RSNECL, RSPECL
Base Part Number NBSG14
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.375V~3.465V
Technology ECL
Subcategory Clock Drivers
Additional Feature RSNECL MODE: VCC = 0 V WITH VEE = -2.375 V TO -3.465 V
Type Fanout Buffer (Distribution), Data
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 16-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
