NBSG11MN
RoHS
/
Package 16-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
QUAD Not Qualified Surface Mount ECL Clock Fanout Buffer (Distribution) IC -40C~85C 12GHz 160ps -2.5/-3.3/2.5/3.3V
PDF
/
Buying Options
Total Price: USD $408.38
Unit Price: USD $408.384251
≥1 USD $408.384251
≥10 USD $394.955748
≥25 USD $392.210282
≥50 USD $389.483893
≥100 USD $381.472962
≥500 USD $354.199599
Inventory: 1176
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:2
Input CML, LVCMOS, LVDS, LVTTL, NECL, RSNECL, PECL
Family 11
Frequency (Max) 12GHz
Propagation Delay 160 ps
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Power Supplies -2.5/-3.3/2.5/3.3V
Qualification Status Not Qualified
Number of Outputs 4
Pin Count 16
Output RSECL, RSNECL, RSPECL
Base Part Number NBSG11
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.375V~3.465V
Technology ECL
Subcategory Clock Drivers
Type Fanout Buffer (Distribution)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
